Machine lnsertion head picks up the scattered pin and inserts into a special plate JlG with vibration feeding. With
complete detection and monitoring, it makes easy operation and production.
·8 sets vision systems ensure the final quality ofincomingmaterial, motion control and insertion
·Marble frame with linear motor, up to μm grade accurary
·Applied for intergrated-link pins on lGBT, mainlyfor automobile, communication,new-energyindustry andaerospace
·User-friendly, simple interface and MES system link
| Parameter Name | Parameter Details |
|---|---|
| Applicable size of fixture | Customization |
| Production rhythm | 0.7S/PC |
| Accuracy of repetition | ±0.01mm |
| Communication | RS485/RS232/SECS/GEM |
| Power consumption | 220V single-phase / 2KW |
| Machine dimension | L2100*W1350*H1700(mm) |
| Weight | 2200KG |
| Operating temperature | 5 - 40℃ |
| Operating humidity | 10 - 90%RH |
| Environment requirement | Non-corrosive gas |
